TestPro CV100

Smart building technologies require its infrastructure to support the multiple IOT and connected devices installed. From digital lighting, wireless access points, security cameras, environmental sensors and more, the TestPro provides you with an extensive test suite to assure infrastructure readiness to support these technologies.

Category:
Enterprise Network Tester Capabilities:
Copper Certification Auto test, Live Wiremap
Single-Pair Ethernet, Fiber Certification Auto test
OTDR, Hybrid Powered Fiber
Fiber Inspection, Multi-Gig Link Speed Qualification
Power over Ethernet (PoE),DC Loop Resistance & Resistance Unbalance, TCL & ELTCTL, Network  Connectivity Testing
Switch Detail, Wireless Network Connectivity Testing
Long Cable Test, RL Locator, NEXT Locator, Shield Locator
MPTL (Modular Plug Terminated Link), Test Results Management
Product Kits & Accessories, Advantages, Documents, Videos, Vertical Spotlight
Tester comes with a certificate of Calibration traceable to NIST.
SIZE: 200mm X 105mm X 50mm
DISPLAY: 5” TFT color touch screen, resolution 800 x 480 pixels
BATTERY – Li-Ion – 3.7V / 13,200 mAh – 9 hr. battery life typical
POWER ADAPTER – 5V, 3A (supplied) – 5-12V (supported) – 2.1mm DC jack.
USB INTERFACES
USB flash drive storage
MicroUSB for connecting to PC RJ-45 SIDE PORT 10/100/1G network connectivity test port.
TEST ADAPTER TO PLATFORM INTERFACE
High-frequency connector rated for 5000 insertion cycles
Hot-swappable MEASUREMENT ENGINE
